TP-Link AX5400 Ceiling Mount WiFi 6 Access Point - EAP673

Blazing-Fast WiFi 6 Speeds (574 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz).

Integrated into Omada SDN, supporting centralized cloud Management, ZTP, and more.

160 MHz Channel double the data at peak transmission times on a single stream.

Advanced features: Supports seamless roaming,Omada Mesh^, and more.

Supports both 802.3at PoE+ and DC (adapter not included) power supply for flexible installations.

WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity.

The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.

With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.

Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.

Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.

Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.

Captive portal (including SMS and Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page.

With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.

Automatically moves dual band devices onto the wider 5GHz band for faster connections.

Ensures large numbers of users have smooth network experiences in high-density business networks.

Increases average network throughput in heavily congested environments.

SPECIFICATIONS:

• Interface: 1× 2.5 Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
• Button: Reset
• Power Supply: 802.3at PoE, 12 V / 2 A DC (Power Adapter Not Included)
• Max. Power Consumption: EU: 20.8 W, US: 22.3 W
• Dimensions: 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
• Antenna: Internal Omni, 2× 4 dBi (2.4 GHz), 4× 5 dBi (5 GHz)
• Bluetooth: Yes
• Mounting: Ceiling / Wall Mounting (Kits Included)
• Coverage: 140㎡ (1500 ft²)
• Concurrent Clients: 250+
• Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
• Frequency: 2.4 GHz and 5 GHz
• Signal Rate: 5 GHz: Up to 4804 Mbps, 2.4 GHz: Up to 574 Mbps
• Wireless Functions: 1024-QAM, 4× Longer OFDM Symbol, OFDMA, Multiple SSIDs (Up to 16 SSIDs, 8 Per Band), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control, QoS (WMM), MU-MIMO, HE160 (160 MHz Bandwidth), Seamless Roaming, Omada Mesh, Band Steering, Load Balance, Airtime Fairness, Beamforming, Rate Limit, Reboot Schedule, Wireless Schedule, Wireless Statistics Based on SSID/AP/Client
• Wireless Security: Captive Portal Authentication, Access Control, Wireless MAC Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
• Transmission Power: CE: <20 dBm (2.4 GHz, EIRP), <23 dBm (5 GHz Band 1 & Band 2, EIRP), <30 dBm (5 GHz Band 3, EIRP); FCC: <25 dBm (2.4 GHz), <28 dBm (5 GHz)
• Omada App: Yes
• Centralized Management: Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller, Omada Cloud-Based Controller
• Cloud Access: Yes (Requires OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
• Email Alerts: Yes
• LED ON/OFF Control: Yes
• Management MAC Access Control: Yes
• SNMP: v1, v2c, v3
• System Logging: Local/Remote Syslog
• SSH: Yes
• Web-Based Management: HTTP/HTTPS
• L3 Management: Yes
• Multi-Site Management: Yes
• Management VLAN: Yes
• Zero-Touch Provisioning: Yes (Requires Omada Cloud-Based Controller)
• Certification: CE, FCC, RoHS

• System Requirements: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux
• Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH Non-Condensing
• Storage Humidity: 5–90% RH Non-Condensing

WHAT’S IN THE BOX:

• EAP673 x1
• Ceiling/Wall Mounting Kits x1
• Installation Guide x1

WARRANTY:

• 24 Months
