Ubiquiti UISP airMAX AC 5GHz 22dBi 45° Sector Antenna

Ubiquiti's AIR-S522AC is a 5GHz 22dBi, 45° airMAX AC sector antenna designed to seamlessly integrate with Ubiquiti's AC Rockets providing noise isolation and improved beam performance in co-location deployments.

*Note: Radio not included.

FEATURES:

• Highest 22 dBi Gain: Provides the highest power output in the airMAX AC sector lineup for maximum distance and strong, clean signal delivery to far-away clients.
• Ultra-Focused 45° Beamwidth: Features a tight 45-degree horizontal coverage angle that heavily restricts side-noise and allows you to densely cluster multiple antennas on a single tower.
• Superior Noise Immunity: Equipped with an integrated deflector shield that aggressively reduces sidelobes and backlobes, maximizing the Signal-to-Noise Ratio (SNR) in crowded frequency spaces.
• 5 GHz Frequency Range: Operates wide across the 5.10 to 5.85 GHz spectrum.
• Dual-Linear 2x2 MIMO: Utilizes simultaneous vertical and horizontal polarization to optimize aggregate data throughput.
• Toolless Rocket Mount: Features a native snap-in bracket on the back for plug-and-play integration with Rocket 5AC and RocketM5 radios.
• Industrial Build: Weatherproof design featuring an integrated bubble level for exact alignment and wind survivability up to 200 km/h (125 mph).

SPECIFICATIONS:

• Dimensions: 750 × 215 × 94 mm (29.5 × 8.5 × 3.7")
• Weight: 6 kg (13.2 lb)
• Wind Survivability: 200 km/h (125 mph)
• Wind Loading: 347 N @ 200 km/h (78 lbf @ 125 mph)
• Mounting: Universal Pole Mount, RocketM Bracket, and weatherproof RF jumpers included
• Frequency Range: 5.10–5.85 GHz
• Antenna Gain: 22 dBi
• Electrical Downtilt: 2°
• Electrical Beamwidth: 4°
• VPOL Beamwidth: 45° (6 dBi)
• Max. VSWR: 1.5:1
• Polarization: Dual-Linear
• Cross-pol Isolation: 30 dB minimum
• ETSI Specification: EN 302 326 DN2
• NDAA Compliant: Yes

WHAT’S IN THE BOX:

• AM-5AC22-45 Antenna Panel (featuring an integrated bubble level for exact alignment) x1
• Protective Shroud (weatherproof cover for the radio enclosure) x1
• U-Brackets x2
• Pole Brackets x2
• Pole Clamps x2
• Weatherproof RF Cables / Jumpers (SMA-to-SMA pigtails to link the antenna to the radio) x2
• Mounting Hardware Kit (4x M8x135 Carriage Bolts, 4x M8x20 Serrated Flange Bolts, and 8x M8 Serrated Flange Nuts) x1
• Quick Start Guide x1

WARRANTY:

• 12 Months
