Ubiquiti UniFi 10Gbps PoE++ 24 Port Ethernet Surge Protector

Ubiquiti's UACC-ETH-SP-Panel-24 is a 24-port rack-mountable UniFi Surge Protector with up to 10Gbps Ethernet, PoE+++ passthrough, and 20kA surge discharge for indoor installations.

*Note: Ports are NOT switched. Only paired ports are passthrough.

FEATURES:

• 24-Port High Density: Provides inline, bidirectional protection for up to 24 Ethernet connections in a single 1U rack space.
• 10 Gbps Data Speeds: Engineered to support massive multi-gigabit line speeds up to 10 Gbps per port with zero packet drop.
• PoE++ Passthrough: Safely handles high-wattage power lines to protect demanding hardware like exterior PTZ cameras and access hubs.
• Heavy-Duty 20kA Protection: Absorbs up to a 20kA surge discharge per port to instantly ground dangerous electrical spikes and EMPs.
• Shielded SGCC Steel Chassis: Built from rugged SGCC steel with metal RJ45 ports that automatically ground shielded cables (STP) to the rack.
• Industrial Weatherproofing: Rated to withstand extreme internal or enclosure temperatures ranging from -40 to 80°C.

SPECIFICATIONS:

• Dimensions: 442.4 x 134 x 43.7 mm (17.4 x 5.3 x 1.7")
• Weight: 2 kg (4.4 lb)
• Enclosure Material: SGCC steel

• Networking Interface: (48) RJ45 female connectors
• DC Spark-Over Voltage: 90V @ 100V/s
• Max. Impulse Spark-Over Voltage: 600V @ 1kV/µs
• Discharge Current: 20kA
• Insulation: Max. resistance: 1G ohm @ 50V
• Max. Capacitance: 1.0 pF @ 1 MHz
• Data Line Protection: Up to 10 Gbps
• PoE Support: ✓
• ESD/EMP Protection: Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs
• Ambient Operating Temperature: -40° to +80° C (-40° to 176° F)
• Ambient Operating Humidity: 10 to 90% noncondensing

WHAT’S IN THE BOX:

• UACC-ETH-SP-Panel-24 Chassis (1U rackmount surge protector) x1
• Grounding Screw & Stud Kit (For chassis bonding to standard server rack earth ground) x1
• Rack Mount Screws & Cage Nuts Set x1
• Installation Guide x1

WARRANTY:

• 12 Months
